0.10 to 100 H.p. (0.075 to 75 K.W.) Frame 63 to 250M in 2, 4, 6, 8, 10, 12, 14, 16, 18, 20 and 24 Pole

Dimensions according to IS 1231 & IS 2223

All Three phase Motor are supplied in a robust, rugged cast iron frame with integral feet. On Request we can supply motor in aluminum Presser Die cast body up to 100 L frame.

All Three phase Motors are continuous (S1) rated to comply with performance standards.

Standard Three phase motor Supply volts 415 ± 5% 3 phase 50 Hz. ± 3% We are also capable for Manufacturing three phase motor in different volts Like 220, 380, 460, 525 and frequency.

We are supplying motor with Ingress protection 44 as defined in IS: 4691. Motors can be supplied with IP-54 and IP-55 on request.

Three Phase Motors are supply with class B & F insulation as standard feature. Also supply H on request of customer.

All Motor Rotors are of high-pressure E.C. Grad aluminum die-cast. Every rotor is dynamically balanced. It’s make motor low amplitudes of Vibration & noise

Shaft made from high carbon steel to provide exceptional Strength & rigidity to minimize deflection. Motor Rotor is positive locking with joint so that cannot move on high Full lord Torque.

Bearings are adequately lubricated with lithium based high temp up to 150 deg. All the motors are supplied with C3 ball bearing & fully charged with lithium base grease at the time of assembly.

Three phase Standard motor Supply with Enclosure T.E.F.C. (Totally Enclosed Fan Cooling).

We can also supply motor with ptc Switch on Demand of Customer. It can provide motor extra safety form over lord protection. It help in motor loner motor life cyclo and life span it work up to 15 to 30 year

All Three phase Motor Supply with Terminal box on top position For Foot mounted (B3). Other position box like left or right supply on customer request

All Three Phase Motor provided with minimum two earthling terminals. One in the terminal box and other on foot.

All Three phase motor are painted with semi glossy synthetic enamel paint. However, sp. Paint is available on request.
