We have wide production Range in Two speed motor.
0.25 to 50 Hp. (0.18 to 37 Kw.)
Two speed motor are offer in 2/4, 2/6, 2/8, 4/6, 4/8, & 6/8 poles. (3000/1500, 3000/1000, 3000/750, 1500/1000, 1500/750 & 1000/750) At 50 Hz.
Dual sped motor available in single winding 2/4, 4/8, 4/6 and 6/12 other pole in double winding. Two speed motor are suitable to 415 ± 5 % 50 Hz ± 3% Combined ± 6 %. On customer request we are also able supply motor in 220, 380, 460, 525 volts on HZ. 50 or 60 also

Dual Speeds Motor are supplied in a robust, rugged cast iron frame with integral feet. On Request we can supply motor in aluminum body up to 100 L frame.

All dual speed motor is supplied with 'F' class insulation but temperature rise restricted to 'B' class.

Dual Speed Motors are supply with "F" Class insulation as standard feature. Also supply H on request of customer.

We are supplying motor with Ingress protection 44 as defined in IS: 4691. Motors can be supplied with IP-54 and IP-55 on request.

Shaft are Made from high carbon steel to provide exceptional Strength & rigidity to minimize deflection.

Rotors are of high-pressure E.C. Grad aluminum die-cast. Every rotor is dynamically balanced. It's made motor low amplitudes of Vibration & noise.

Bearings are adequately lubricated with lithium based high temp up to 150 deg. All Dual Speed motor are supplied with C3 ball bearing & fully charged with lithium base grease at the time of assembly.

Two Speed Motor Supply with Enclosure T.E.F.C. (Totally Enclosed Fan Cooled).

We can also supply Two Speed Motor with T.O.P Switch on Demand of Customer. It can provide motor extra safety form over lord protection.

Dual speed Motor Supply with Terminal box on top position For Foot mounted (B3). Others position box like left or right supply on customer request.

Motor provided with minimum two earthling terminals. One in the terminal box and other on foot.

All motor is painted with semi glossy synthetic enamel paint. However, sp. Paint is available on request.

Dual speed motor is use in Many applications which multiple speeds are required. Pharmaceuticals, Crane, hoist, lift, construction, Chemical industries, Food equipment, Ceramic industries Machine tools for different application. We can also provide dual speed gear motor, dual brake motor.
