Three Phase Motor

We having wide production range of vibrating motor 0.10 to 15 Hp. (0.075 to 11 K.W.) in 2, 4, 6, 8, 10 & 12 Pole. In Three Phase Vibrating Motor Supply volts 415 ± 5% 3 phase 50 Hz. ± 3% we are also capable for manufacturing vibrating motor in different volts and frequency Like 220, 380, 460, 525 in 50 or 60 Hz.

Single Phase Motor

0.25 H.P. TO 2 H.P. in 2,4 pole 1 phase supply volts 215 ± 5% 50Hz. ± 5% on customer request we are also able supply motor in 110 volts on 50 or 60 Hz Also.

All Vibrating motor are supplied in a robust, rugged steel casting frame with integral feet.

All Vibrating motors are continuous (S1) rated.

The Vibratory Motors is a three-phase synchronous motor that has eccentric weights (unbalance weight) mounted at the ends of the Rotor shaft. The rotating shaft causes centrifugal forces, which can be adjusted by moving the weights it create a vibration.

Vibratory Motors Insulation class F enhances the safety under continuous operation conditions and at high ambient temperatures. Motor is tropicalized and designed for an extended voltage range.

We are supplying motor with Ingress protection 44. Vibrating Motors can be supplied with IP-54 and IP-55 on request.

Vibrating motor are supply with class B & F insulation as standard feature. Also supply H on request of customer.

All Vibrating motor Rotors are of high-pressure E.C. Grad aluminum die-cast. Every rotor is dynamically balanced. It's made motor low amplitudes of Vibration & noise

Shaft made from high carbon steel to provide exceptional Strength & rigidity to minimize deflection. Motor Rotor is positive locking with joint so that cannot move on high Full lord Torque.

Vibratory Motors the right type of bearing for every application guarantees long service life even continuous operation. All vibratory motors are permanently lubricated for normal operation. Large capacity motor can be re-lubricated for average application. Sp. Type of grease is used in vibratory motor.

Vibrating motor Supply with Enclosure T.E.S.C. (Totally Enclosed surface Cooled)

We can also supply motor with T.O.P Switch on Demand of Customer. It can provide motor extra safety form over lord protection.

All Vibrating motor provided with minimum two earthling terminals.

All Vibrating motors are painted with semi glossy synthetic enamel paint. However sp. Paint is available on request.

Mining Industry, Food Industries, Construction, Parma industries, ceramic Industries, Foundry, Steel Industries, Chemical Industries, Recycling industries, Plastic Industries, Ect.
